Nikon 4K912-116 System Amplifier Module

Nikon 4K912-116 System Amplifier Module

 Introduction

Nikon 4K912-116 system amplifier module, dedicated driver amplifier board for NSR series lithography machine equipment.

Product Features:

1. Stable signal amplification gain ensures high-precision servo drive output of the motion mechanism

2. Anti interference board design, suitable for strong electromagnetic complex working conditions of semiconductor equipment

3. Fast response speed, achieving high-speed positioning and tracking control of the mechanism

4. Built in fault detection circuit, outputting fault signals in abnormal states

5. Onboard temperature monitoring, automatic overheating protection to prevent module burnout

6. Standard card slot installation, easy insertion, replacement, and maintenance

7. Signal closed-loop feedback, real-time correction of output deviation

8. Suitable for precision motion axis of lithography machine, reliable long-term continuous operation

9. Board level filtering processing to reduce signal noise interference

10. Compatible with Nikon NSR-S620D lithography machine control system

Product Parameters:

1. Application device: Nikon NSR-S620D lithography machine

2. Power supply: DC power supply for the internal backplane of the device

3. Signal interface: Backplane gold finger interface, servo signal input and output

4. Protection: overcurrent, overheating, signal abnormality detection protection

5. Working environment: Temperature controlled environment inside the semiconductor equipment cabinet

Nikon 4K912-116 is mainly used for precision motion axis signal amplification and drive control of lithography machines

Product imag
