Nikon 4S013-684-1 Semiconductor Amplifier Module

Nikon 4S013-684-1 Semiconductor Amplifier Module

 Introduction

Nikon 4S013-684-1 is a servo amplifier module for NSR lithography machine RY-RD, used for linear motor power drive and signal amplification of workpiece and mask stages.

Application areas

1. Linear motor servo drive for lithography machine worktable

2. High precision motion control of lithography equipment mask stage

3. Closed loop amplification processing of wafer exposure platform position

4. Scanning lithography machine motion axis power output unit

5. Semiconductor exposure equipment positioning module driver

6. Grating feedback signal processing for lithography equipment

7. Power amplification of precision displacement actuator

8. Chip lithography equipment cabinet plug-in driver module

9. Motion control system for micro nano exposure platform

10. Motor drive unit for optical scanning equipment

Product Parameters

1. Three phase 200V input, rated 7A, 50/60Hz power supply

2. Multi channel servo power amplifier, compatible with linear motors

3. Differential encoder signal reception, fast position closed-loop response

4. Modular plug-in card structure, compatible with lithography machine cabinets

5. Built in overcurrent, overvoltage, and overheating fault protection

In summary, the Nikon 4S013-684-1 amplifier has fast dynamic response and high positioning accuracy, making it the core driving component of the Nikon NSR series lithography machine motion table

Product imag
