Kawasaki 0190-25866 Robot Main Controller

Kawasaki 0190-25866 Robot Main Controller

 Introduction

Kawasaki 0190-25866 is the main controller for Kawasaki robots used in semiconductor equipment, which realizes the motion logic and servo drive control of clean robotic arms.

Application areas

1. Control of semiconductor wafer box handling robot arm

2. Motion control of wafer vacuum transfer robot

3. Internal mechanical arm operation control of lithography equipment

4. Etching machine chamber wafer loading and unloading drive

5. Control of wafer transfer in thin film deposition equipment

6. Scheduling of ion implantation machine wafer manipulator

7. Automatic transfer of semiconductor measurement equipment samples

8. Chip packaging clean robot main control

9. Logical processing of vacuum manipulator in FAB workshop

10. Collaborative scheduling of multiple robotic arms for semiconductor equipment

Product Parameters

1. Supports up to 8-axis motion control and can achieve multi robot linkage

2. Single phase AC200-220V ± 10% power supply, 50/60Hz industrial frequency

3. Fully digital servo control, supporting linear, circular arc, and joint interpolation

4. Configure Ethernet and RS232 communication to interface with semiconductor device hosts

5. The working temperature is 0-45 ℃, with multiple safety protections such as overcurrent and emergency stop

Overall, the Kawasaki 0190-25866 controller has fast motion response and high safety level, making it the core control unit for clean robotic arms in semiconductor production lines.
