AMAT 0190-26387 Sensor Interface Module

AMAT 0190-26387 Sensor Interface Module

 Introduction

The AMAT 0190-26387 sensor interface module is a dedicated signal conversion board for semiconductor machines, used for signal acquisition and conversion of various sensors in the cavity. The core product features are as follows:

1. Compatible with multiple types of process sensors, compatible with analog and digital signal inputs

2. Low signal conversion delay ensures real-time transmission of sensor data

3. Onboard filtering circuit to resist electromagnetic interference in plasma environment

4. Multiple independent signal channels can be connected to multiple sets of sensors simultaneously

5. Equipped with overvoltage, overcurrent, and electrostatic protection to protect front-end sensors

6. Onboard LED indicator light, visually displaying channel and fault status

7. Dedicated bus protocol, compatible with AMAT host control system

8. Low signal loss and undistorted processing of weak sensing signals

9. Plug in card rack installation, easy disassembly and replacement operation

10. Three proof coating on the board, suitable for dust-free workshop production environment

11. Built in basic diagnostic function, supporting channel status reporting

12. Compact board size, saving installation space inside the cabinet

13. Support hot swappable replacement to shorten device downtime

14. Wide operating temperature range, suitable for internal temperature conditions of the machine

15. Signal isolation design to avoid mutual interference between channels

The AMAT 0190-26387 sensor interface module has high reliability and is commonly used in etching and thin film process chambers. It is a key component of semiconductor equipment sensor signal links

Product imag
