NI PCI-6509 Digital Input/Output Card

NI PCI-6509 Digital Input/Output Card

 Introduction

NI PCI-6509 digital input/output card, PCI bus industrial control acquisition board, with a large number of channels.

1. NI PCI-6509 has 96 bidirectional digital IO channels

2. TTL/CMOS level compatibility, compatible with most industrial peripherals

3. Single channel 24mA high drive, direct drive solid-state relay

4. Flexibly switch input and output modes by port

5. NI PCI-6509 supports programmable power on output status

6. Comes with a watchdog, automatically switches to a safe level in case of malfunction

7. Programmable digital filtering to eliminate signal glitches and jitter

8. Support signal change interrupt detection

9. Compatible with NI DAQmx driver, easy to develop and debug

10. Standard PCI slot for direct installation of industrial control host

11. 100 pin SCSI interface, external terminals for easy wiring

12. Port total current limit protection to prevent overload damage

13. Support multi card parallel connection and expand IO point scale

14. Industrial grade board, anti-interference and adaptable to workshop conditions

15. The software can read the channel status for easy troubleshooting

The NI PCI-6509 digital input/output card is commonly used for equipment testing and automated signal interaction, with good stability.

Product imag
