ACS UDMIc40024N000 motion control module

Introduction

ACS UDMIc40024N000 motion control module, EtherCAT bus four axis drive control integrated unit, compatible with SPiiPlus motion control system.

1. ACS UDMIc40024N000 four axis integrated drive, capable of independently controlling four motors

2. Support multiple types of motor drives including servo, stepper, and voice coil

3. EtherCAT industrial bus, multi axis synchronous high real-time performance

4. ACS UDMIc40024N000 is compatible with incremental and absolute encoder feedback

5. S-curve acceleration and deceleration algorithm, with minimal start stop impact during motion

6. ACS UDMIc40024N000 high-frequency servo sampling, high positioning repeatability accuracy

7. Built in digital IO channel, compatible with limit and sensor signals

8. Multiple hardware protections for overcurrent, overheating, and overload

9. ACS UDMIc40024N000 status LED light, visually displaying axis operation faults

10. Support external brake output, compatible with brake motor

11. ACS UDMIc40024N000 metal shell shielding, resistant to electromagnetic crosstalk interference

12. Two installation methods of DIN rail/panel, flexible cabinet layout

13. Fault code self check, convenient for equipment maintenance and troubleshooting

14. ACS UDMIc40024N000 DC wide voltage power supply, suitable for machine power supply environment

15. Compact in size, suitable for integrating devices in small spaces

The ACS UDMIc40024N000 motion control module is commonly used for semiconductor testing stations and precision automation multi axis motion control.

Product imag
