Silicon Graphics Si5350/51-20QFN-EVB Generator Evaluation Board

Silicon Graphics Si5350/51-20QFN-EVB Generator Evaluation Board

Product Details Introduction

Silicon Graphics Si5350/51-20QFN-EVB generator evaluation board, used for clock chip testing and scheme debugging, with comprehensive functions and convenient use.

Model Si5350/51-20QFN-EVB, dedicated clock generator evaluation board

Equipped with Si5350/51 series clock chip and packaged in 20QFN

Supports wide range clock frequency output and adapts to various testing needs

Onboard independent power supply circuit, can be powered directly through USB

Reserved external clock access interface, compatible with internal and external reference signals

Equipped with I ² C control interface, convenient for parameter reading, writing and configuration

Multiple clock output channels to meet synchronous testing of multiple devices

Support multiple working modes, switch flexibly and adapt to different scenarios

Equipped with status indicator lights to visually view the operating status of the equipment

Integrated jumper module, capable of quickly switching voltage and functional modes

Stable signal output, low phase jitter, high testing accuracy

Paired with dedicated upper computer software, graphical operation is simple and easy to understand

The board layout is neat, the interface partition is clear, and the wiring is convenient

Suitable for chip performance verification, product prototype development and debugging

Solid workmanship, strong anti-interference ability, suitable for long-term use in laboratories

In summary, the Si5350/51-20QFN-EVB generator evaluation board has complete functions and is a practical supporting component for clock chip development, testing, and maintenance

Product imag
