GIDINGS&LEWIS 502-03550-00 Input Module

1、 Product Overview

502-03550-00 is a digital input module in the Giddings&Lewis control system, used to collect switch/status signals from industrial sites and transmit them to the controller for logical processing. This module is commonly used in CNC machine tools, automated production lines, and robot control systems.

2、 Technical features

Input channel: Provides multiple independent digital inputs to meet the requirements of multi-point signal acquisition.

Voltage level: Usually supports 24VDC standard industrial signal input.

Isolation protection: Each input channel is isolated from the system bus to enhance anti-interference capability and avoid on-site electrical noise affecting the control system.

Signal compatibility: It can collect input signals from sensors, buttons, limit switches, relay contacts, etc.

Status indication: The module is equipped with input status indicator lights for easy on-site debugging and maintenance.

Reliability: Equipped with overvoltage protection and filtering circuit design to reduce false triggering and interference.

3、 Structure and Installation

Modular design: can be directly installed in G&L control racks or compatible I/O systems.

Wiring method: Using standard terminal interfaces, supporting fast wiring and maintenance.

Industrial grade construction: sturdy and durable, suitable for long-term operation in complex industrial environments.

4、 Application Fields

CNC machine tool

Collect limit switches, workpiece clamping signals, coolant level signals, etc.

Automatic production line

Input detection signals from photoelectric sensors, proximity switches, travel switches, etc. to achieve process control.

robot system

Obtain signals such as emergency stop switch, mechanical arm position confirmation, and workpiece in place.

Packaging and Printing Machinery

Collect control signals such as tension detection, roll positioning, and cutter origin.

Logistics and warehousing equipment

Input cargo detection and sensor position feedback to achieve handling and stacking control.

Product imag
