GE IS230PCAAH1A Analysis of I/O Components

(English description: GE Mark VIe I/O Pack - IS230PCAAH1A Analog Input Module)

1、 Product Overview

IS230PCAAH1A is an analog input I/O module (I/O Pack) used in GE Mark VIe control systems to collect analog signals from the field and transmit them to controllers (such as Mark VIe or Mark VIeS systems). This module has high precision, industrial grade anti-interference capability, and system redundancy support, and is widely deployed in GE's gas turbine, steam turbine, compressor, and power plant automation systems.

2、 Technical parameters

Module type: Analog Input I/O Pack

Product Series: GE Mark VIe/VIeS Control System

Model code: IS230PCAAH1A

Input signal type:

Current input (4-20 mA, 0-20 mA)

Voltage input (± 5V, ± 10V) - depends on the I/O Terminal Board configuration

Number of channels: Typically 10-20 analog input channels (depending on the type of terminal board connected)

Communication interface:

Communicate with the controller through IONet network (redundant Ethernet)

I/O Pack is installed on the terminal board and connects signals and power through the backplane

Power requirements:

Backup power supply from I/O Terminal Board (usually 28 VDC)

Diagnostic function:

Channel level short circuit, open circuit, self check diagnosis

Channel status indicator LED

Support redundancy: Supports I/O redundancy in conjunction with dual channel terminal boards

Work environment:

Temperature range: -30 ° C~+65 ° C

EMC anti-interference design for industrial environment

Compatible with multiple types of I/O Terminal Boards (such as TBCA, TBCC)
