Gasonics A94-1168 810-2850 Interface Module

Gasonics A94-1168 810-2850 Interface Module

Product Details Introduction

product overview

The Gasonics A94-1168 (part number 810-2850) interface module is a communication and control interface circuit board used in Gasonics plasma equipment, mainly responsible for signal connection, data exchange, and status feedback between various subsystems within the equipment. This module is commonly found in Aura series plasma cleaning equipment and is an important component of system logic control.

Technical Parameter

Model: A94-1168

Material Number: 810-2850 (Internal Identification Number)

Type: Multi channel Interface Board (I/O Interface Board)

Function: Used for digital/analog signal transmission, level conversion, and status signal feedback

Interface form: Multiple sets of multi pin connectors, compatible with control motherboards or sensor modules

Installation method: Standard plug-in structure, fixed inside the main control frame of the equipment

Applicable equipment: Gasonics Aura 1000, Aura 2000 and other plasma cleaning systems

Application scenarios

Signal coordination and interface conversion

The module is responsible for distributing control signals from the main control system to various execution units, such as air valves, RF power supplies, vacuum systems, etc., or collecting feedback signals and returning them to the main control board.

Equipment operation status transmission

Real time transmission of process parameters and operational status of various subsystems, such as air pressure, temperature, plasma state, etc.

Integrated Control System Communication Hub

As the central interface board of the control system, it is used to connect the data link between the upper level processor and the lower level electrical equipment.

Product imag
