Orion ETN23A-SC-B Heat Exchanger

Orion ETN23A-SC-B Heat Exchanger

 Introduction

Orion ETN23A-SC-B semiconductor refrigeration heat exchanger (Pel Thermo), CMP cleaning equipment megasonic module temperature control unit.

Product Features:

1. Peltier thermoelectric refrigeration achieves precise temperature control of fluids

2. Fast temperature regulation response, suitable for cleaning process temperature requirements

3. Built in temperature sensor, real-time collection of medium temperature

4. Temperature over limit alarm output to protect the process module

5. Compact body, suitable for small internal spaces of devices

6. Support IO signal docking with the entire PLC system

7. Internal flow channel anti-corrosion, compatible with chemical cleaning media

8. Comes with built-in fault diagnosis, and fault codes are easy to troubleshoot

9. Filter protection to reduce the risk of pipeline blockage

10. Adapt to the production line for continuous operation 24/7

Product Parameters:

1. Temperature control range: 20-85 ℃

2. Refrigeration capacity: 280W

3. Power supply: 43VDC, 16.3A

4. Interface: Fluid pipeline, switch signal interface

5. Protection: Over temperature, over-current, and abnormal alarm protection

Orion ETN23A-SC-B is mainly used for semiconductor CMP cleaning, megasonic module temperature control and heat dissipation station

Product imag
