 Introduction

#Dtims CPB4612-LF control board

Dtims CPB4612-LF is a 6U CompactPCI industrial control board, suitable for semiconductor and industrial control equipment frame systems.

1. Dtims CPB4612-LF complies with PICMG industrial bus standards and has a plug-in installation in the chassis

2. Onboard dual gigabit Ethernet ports to meet high-speed data transmission and communication requirements

3. Equipped with PMC expansion slot, it can flexibly add daughter board expansion function

4. Supports ECC memory, providing stronger stability for data computation and operation

5. Dtims CPB4612-LF integrated watchdog timer, automatic reset protection system upon system crash

6. Support IPMI device management and remote monitoring of board operation status

7. Onboard graphics processing unit, capable of outputting display signals

8. Dtims CPB4612-LF supports IDE storage interface and can be connected to an external hard drive for data storage

9. 6U single slot structure, occupying a single slot in the chassis, saving cabinet space

10. Gold finger backboard docking, integrated signal and power supply access

11. Dtims CPB4612-LF wide temperature working design, suitable for high and low temperature environments inside the cabinet

12. Perform EMC optimization on the circuit to resist electromagnetic interference in industrial sites

13. Support continuous operation for 7 × 24 hours without interruption for a long time

14. Dtims CPB4612-LF lead-free LF version, meeting industrial environmental protection process requirements

15. Standardized hardware interface, easy and convenient replacement of spare parts

The Dtims CPB4612-LF control board serves as the core control board of the CompactPCI shelf, providing computing, communication, and peripheral expansion capabilities for industrial equipment.

Product imag
