ASYST 3000-1171-01 Controller Interface Module

ASYST 3000-1171-01 Controller Interface Module

 Introduction

The ASYST 3000-1175-17 controller interface module is a semiconductor equipment board that enables signal interaction between the main control and the robotic arm unit.

1. ASYST 3000-1175-17 is responsible for the signal docking between the machine master control and the robotic arm

2. Multiple I/O channels, transmitting position and interlock control signals

3. Optocoupler isolation to resist electromagnetic interference inside the cabinet

4. ASYST 3000-1175-17 channel indicator light, visually displaying the working status of the point position

5. Power on self-test, quickly identify channel hardware faults

6. Support safe interlock logic processing for robotic arms

7. ASYST 3000-1175-17 fault data local cache for easy maintenance

8. Slot rack mounted board, easy to disassemble, replace and maintain

9. Suitable for 24V machine power supply, with good voltage adaptability

10. ASYST 3000-1175-17 has channel short-circuit protection function

11. Fast signal response ensures synchronous movement of the robotic arm

12. Industrial components, capable of withstanding high and low temperature conditions in cabinets

13. ASYST 3000-1175-17 has low power consumption and supports 7 × 24-hour continuous operation

14. Compatible with the overall architecture of the ASYST robotic arm series

15. Can provide feedback on the operating status of the equipment to the upper level controller

The ASYST 3000-1175-17 controller interface module is commonly used for signal control of semiconductor wafer transfer robots.

Product imag
