Silicon Graphics 030-1054-001 I/O Control Board

Silicon Graphics 030-1054-001 I/O Control Board

Product Details Introduction

The Silicon Graphics 030-1054-001 I/O control board is an original I/O interface board for SGI Octane series workstations, responsible for high-speed input and output management. It has complete interfaces, stable transmission, and strong compatibility.

The model is 030-1054-001, SGI Octane original I/O control board.

Compatible with Octane workstation XIO bus architecture, dedicated I/O expansion module.

Integrated 10/100Mbps Ethernet interface, supporting network wake-up and PXE boot.

Equipped with Ultra2 SCSI controller, it can connect storage devices at high speed.

Equipped with USB 1.1 interface, DB9 serial port, and PS/2 keyboard and mouse interface.

Integrated audio input and output, supporting multimedia voice and sound processing.

Using XIO high-speed bus, it has high bandwidth, low latency, and high throughput.

Onboard FIFO cache improves DMA transfer efficiency and reduces CPU usage.

Industrial grade 8-layer PCB material, resistant to vibration, interference, and good heat dissipation.

Surface mount technology ensures uniform and reliable solder joints, and long-term stable operation.

Compatible with IRIX 6.5 system, with complete driver adaptation and plug and play functionality.

Support hot plugging, maintenance without shutting down, easy to replace online.

Standard XIO card size, easy installation, precise positioning, and firm fixation.

Equipped with overcurrent, overvoltage, and short circuit protection to ensure the hardware safety of the system.

Original SGI quality, suitable for Octane workstation maintenance, replacement, and upgrade.

In summary, the 030-1054-001 I/O control board, with its original adaptation, high-speed bus, rich interfaces, and comprehensive protection, is the core I/O expansion and replacement component of the SGI Octane series devices, suitable for professional graphics processing, scientific computing, and multimedia application scenarios.
