GIDINGS&LEWIS M.1302.8416 servo drive

GIDINGS&LEWIS M.1302.8416 servo drive

Product Details Introduction

Product Overview

GIDINGS&LEWIS M.1302.8416 servo drive is a high-performance single axis servo drive module designed specifically for CNC machine tools and industrial automation systems. This driver can accurately control AC or brushless DC servo motors, achieving closed-loop control of position, speed, and torque. M. The 1302.8416 driver exhibits excellent performance in high dynamic response, stability, and reliability, and is a key execution component in G&L servo control systems.

Technical parameters (typical)

Number of control axes: single axis servo drive

Input power supply: three-phase AC industrial power supply (typical 220V/380V/460V)

Output capability: Driven by medium to high power servo motors, stable current output

Control modes: position control, speed control, torque control

Feedback interface: Supports incremental encoders, high-resolution parsers, and closed-loop control

Communication interface: high-speed data exchange with G&L controller or upper system

Protection function: overvoltage, undervoltage, overcurrent, overheating, short circuit, and encoder fault protection

Cooling method: air cooling or natural cooling

Response characteristics: Fast dynamic response, meeting the requirements of frequent start stop and high-speed acceleration and deceleration

Application scenarios

CNC machine tool

Control the spindle or feed axis to achieve high-speed cutting, precision machining, and automatic tool changing operations.

Multi axis automated assembly system

Drive robot joints or multi axis workstations to ensure precise synchronization of complex movements.

High speed packaging and printing equipment

Control feeding, cutting, packaging, or printing heads to achieve high tempo and high-precision movements.

textile machinery

Drive the winding machine, feeding device, and tension control system to improve the stability of the production process.

Research and Testing Platform

Support multi axis servo test benches and dynamic testing equipment to achieve high-precision experimental motion control.

Special processing equipment

Drive special process equipment such as cutting, drilling, and spraying to achieve stable and high-precision operation.

Product imag
