GIDINGS&LEWIS 502-02724-51 Interface Circuit Board

GIDINGS&LEWIS 502-02724-51 Interface Circuit Board

Product Details Introduction

Product Overview

The GIDINGS&LEWIS 502-02724-51 interface circuit board is a core signal interface module used in industrial automation and numerical control systems. It is mainly used to transmit digital or analog signals between controllers and peripheral devices, achieving signal acquisition, distribution, and isolation. This module can effectively enhance the signal processing capability and stability of the system, and is an indispensable interface unit in complex machine tools and automated production lines.

Technical parameters (typical)

Interface type: digital input/output or analog signal interface

Number of channels: Multi channel design, supporting multiple signal interactions

Signal isolation: equipped with photoelectric or electrical isolation functions to improve anti-interference ability

Power requirement: Typical 24VDC industrial power supply

Response speed: milliseconds or faster, meeting real-time control requirements

Installation method: Modular card insertion design, can be embedded in cabinets or racks

Protection function: Overload, overvoltage, short circuit, and signal abnormality protection

Status indication: LED display module and channel status for easy debugging and maintenance

Application scenarios

Numerical Control Machine Tool System

As a signal bridge between the controller and servo drivers, stepper motors, and sensors, it achieves precise machining action control.

Automatic production line

Coordinate the signal transmission of assembly, conveying, and sorting equipment to ensure synchronous process actions.

industrial robot

Collect status signals of end effectors and fixtures to achieve multi axis linkage control.

Packaging and Printing Machinery

Manage paper or film position sensor signals to ensure the accuracy of feeding, cutting, and packaging actions.

Energy and Process Control Equipment

Collect sensor signals such as temperature, pressure, and flow rate to provide data support for automation control.

Experimental and testing platform

Provide interface functionality in multi-channel signal acquisition and action control to ensure accurate experimental data.

Product imag
