Atlas Copco PF3007-C-PB-HW Driver

Atlas Copco PF3007-C-PB-HW Driver

Product Details Introduction

1、 Product Overview

Atlas Copco PF3007-C-PB-HW is an intelligent electric tool driver (controller) in the Power Focus 3000 series, designed to provide precision drive and tightening process control for electric tightening tools in small and medium torque ranges (such as Tensor ST, STR, EBL, etc.). The controller has a built-in PROFIBUS (PB) communication interface, making it easy to integrate into industrial automation systems such as Siemens.

Model analysis:

PF3007: Refers to the 07 model in the 3000 series, supporting tools with medium power levels

C: Standard control function, compatible with universal tightening tasks

PB: Integrated PROFIBUS communication protocol interface

HW: Standard hardware configuration

2、 Key functions

Support torque control/angle control/multi-stage tightening/adaptive control/calibration compensation

Compatible with tools such as Tensor ST, SL, STR, ETX, EBL, etc

Integrated PROFIBUS DP interface for easy connection to control systems such as Siemens S7

Support tightening process monitoring and error recognition (such as slipping, under twisting, reverse, etc.)

Local data recording and real-time uploading, supporting integration with MES system

3、 Typical application areas

1. Automotive manufacturing and powertrain assembly

Precision assembly of engine cylinder block, oil pan, gearbox housing, chassis components, etc

Multi station parallel control improves production pace and tightening consistency

2. New energy vehicles (EVs) and battery packaging matching

Precision bolt connections for battery casing, electronic control system, and electric drive assembly

MES docking tightening result binding VIN code, supporting barcode recognition and workstation recognition

3. Manufacturing of household appliances and electrical equipment

Batch torque control in structural connections such as motors, electrical casings, compressors, etc

Fast workstation switching and multi program tightening, suitable for mixed line production

4. Robot tightening unit

Integrate with six axis or SCARA robots to perform automatic tightening tasks

The controller is installed at the end of the robot arm or inside the control cabinet and supports remote management

5. Construction machinery, wind power, and rail transit

Medium load connections for large structural components such as rails, cabins, doors, etc

Support batch management, data traceability, and fault alarm

Product imag
