Product Details Introduction

The Allen Bradley 1783-MS10T is an industrial Ethernet switch under the Allen Bradley brand of Rockwell Automation, belonging to the Stratix 2000 series. This switch is designed specifically for industrial environments to achieve high-speed and stable data communication between industrial Ethernet devices.

2、 Main functions

Port configuration: Provides up to 8 10/100 Mbps Ethernet ports, supporting full duplex and half duplex modes.

Industrial design: sturdy structure, adaptable to harsh industrial environments, including wide temperature range, anti vibration, and anti electromagnetic interference.

Plug and play: No need for complex configuration, supports automatic negotiation and automatic MDI/MDIX switching.

Network Management: Supports basic network management functions such as VLAN (Virtual Local Area Network), port mirroring (some models), flow control, and QoS (Quality of Service).

High reliability: Equipped with redundant power input interfaces, supporting rapid fault recovery.

3、 Technical parameters

Number of ports: 8 10/100 Mbps RJ45 ports

Transmission rate: Maximum 100 Mbps

Working temperature: -40 ° C to 70 ° C (industrial grade)

Power input: Supports redundant power supply, 24V DC (wide range)

Size and installation: DIN rail installation, compact design

Ethernet protocol support: IEEE 802.3, IEEE 802.3u, IEEE 802.3x flow control

MTBF (Mean Time Between Failures): Designed for high reliability and suitable for continuous operation environments

4、 Application Fields

Industrial automation network communication

Networking of production line equipment

Robot control system

process control network

intelligent manufacturing system

5、 Usage suggestions

Choose a suitable power supply and installation environment to ensure good ventilation and heat dissipation.

Utilize the management function of switches to optimize network performance and ensure priority transmission of critical data.

Regularly check the connection status to prevent port or cable failures from affecting system stability.

Combining other equipment from Rockwell Automation to achieve a complete industrial network solution.

Product imag
