Rexroth PPC-R22.1N-T-Q2-G2-NN-FW servo controller

6KGP43075X9XXXA1 AC Driver

Product Details Introduction

1、 Product Overview

Brand: Bosch Rexroth

Model: PPC-R22.1N-T-Q2-G2-NN-FW

Product type: Industrial multi axis motion controller

Series: PPC-R Series

Typical applications: Multi axis servo system control, CNC system, robot automation, packaging machinery, etc

2、 Structure and Module Configuration Description

The segmented meanings of the controller model are as follows:

PPC-R22.1N: Main controller module, installed in RMB02.2 rack

T: Equipped with Ethernet communication interface

Q2: Pre installed DAQ03 module (dual axis control or high-speed input)

G2: Pre installed LAG module (main encoder interface module)

NN: No additional modules installed (U3, U4 empty spaces)

FW: Firmware needs to be ordered separately or loaded through a storage card

3、 Technical parameters

Power supply voltage: 24V DC

Current consumption: maximum approximately 1.2A

Installation method: Vertical plug-in installation on Rexroth RMB02.2 rack

Cooling method: natural air cooling (combined with cabinet ventilation)

Dimensions: Approximately 83mm in width, 182mm in height, and 150mm in depth

Protection level: IP20 (installed in the control cabinet)

Expansion slots: 3 in total (U2, U3, U4)

4、 Main functions

Support multi axis synchronous control

Compatible with Rexroth IndraDrive and EcoDrive servo drives

Support GPP10/GPP11 firmware programs

Support high-speed input, encoder feedback, and logic control

Provide real-time motion control (including interpolation, speed control, position control)

Support Profibus, SERCOS, DeviceNet (through corresponding modules)

Provide diagnostic LED display for easy fault identification

5、 Application Fields

Numerical Control System (CNC)

Automated assembly line

Multi axis servo drive system

Packaging, printing, and textile machinery

Industrial Robot Control System

Woodworking and metalworking equipment
