Silicon Graphics 040-1056-001 I/O Backboard

Silicon Graphics 040-1056-001 I/O Backboard

Product Details Introduction

Silicon Graphics 040-1056-001 is an SGI original I/O backplane used for signal and power interconnection within the chassis. It is the core backplane component for multiple mid to high end SGI workstations/servers.

Model: 040-1056-001 (SGI original I/O backplane)

Functional positioning: Interconnection backplane for system I/O signals, power supply, and expansion bus

Compatible models: mostly used for SGI Octane, Onyx, Origin series chassis

Backboard type: mid/rear I/O backplane, connected to motherboard, power supply, and I/O panel

Bus support: compatible with SGI exclusive/standard buses such as XIO, PCI, GIO32, etc

Interface definition: Onboard dedicated connector, designed to interface with motherboards, power modules, and I/O daughter boards

Signal integrity: multi-layer PCB, impedance control, low crosstalk, low jitter

Power distribution: Integrated high current wiring, distributed multiple DC power supplies (3.3V/5V/12V)

Scalability: Provides multiple slots/interfaces, supports I/O daughter card and graphics card interconnection

Material and process: Industrial grade FR-4 board, anti-oxidation gold finger, stable long-term operation

Protection design: overcurrent/overvoltage protection layout, anti-static grounding design

Chassis adaptation: Standard SGI chassis size, screw fixed, plug and play

System compatibility: compatible with IRIX system, fully matched with original motherboard/power supply/accessories

Purpose: Whole machine assembly, maintenance and replacement of old equipment, replacement of backplate faults

Original factory quality: original disassembly/brand new spare parts, strong compatibility, low failure rate
