ATLAS COPCO TC54S-CC Driver

ATLAS COPCO TC54S-CC Driver

Product Details Introduction

1、 Product Overview

TC54S-CC is a servo drive launched by Atlas Copco, belonging to the TC5000 series product line. This driver is mainly used to control servo motors in multi axis electric tightening systems, and has the characteristics of high precision, high response, and low delay. The "CC" in the model generally indicates that its communication interface supports CANopen or other customized communication protocols, and is used in conjunction with upper level systems such as Power MACS or Power Focus controllers.

2、 Technical features and functions

Product model: TC54S-CC

Control method: precise torque, angle, and speed control

Compatible platform: Compatible with Atlas Copco multi axis tightening system (such as Power MACS 4000)

Communication protocol: Supports CC (usually CANopen Communication or Custom Communication)

Real time monitoring: supports data collection and curve recording during the tightening process

Driver support:

Control the action sequence of servo tools

Feedback motor status (position, speed, current)

Fault self diagnosis and remote configuration

Security mechanism: equipped with multiple protections such as overheating, overload, and short circuit

3、 Typical application areas

1. Automobile manufacturing

Multi station tightening process for engine, gearbox, frame, etc

Multi axis linkage control improves rhythm and consistency

Support full process traceability of bolt tightening quality

2. Construction Machinery and Heavy Industry

High torque applications, such as heavy machinery assembly, welding fixture locking, etc

Realize stable torque output and high-strength bolt connection

3. Home appliances and electronic assembly

Small fastening equipment with high requirements for multi axis collaborative control

Precise control to prevent excessive tightening or damage to the product

4. Aerospace

Precision fastening operation for aircraft components

Combining servo system to achieve dual guarantee of reliability and traceability

Product imag
