193X725AAG01 generator card

193X725AAG01 generator card

Product Details Introduction

Brief introduction

The GE 193X725AAG01 generator card is an important module in the GE 193X series, specifically designed for generator control systems. This module is used to collect the working status and performance parameters of the generator, and convert them into the control signals required by the system. It is commonly used in power plants, wind power, ships, and other application environments that require generator monitoring and control.

2、 Core functions

Generator parameter collection: Real time collection of working parameters of the generator, such as output voltage, current, frequency, speed, etc.

Status monitoring: Monitor the status of the generator, including load, current fluctuations, temperature, etc., to ensure the safe operation of the generator.

Signal processing and conversion: Convert the collected analog signals into digital signals, or convert digital signals into operable control signals.

Protection function: It has short-circuit protection, overload protection, overvoltage protection and other functions to prevent damage to the generator in case of abnormalities.

Communication function: Supports communication with other modules of the control system, provides real-time feedback, and ensures the coordinated operation of the generator.

Data recording and diagnosis: It can record key operational data, support fault diagnosis, alarm and maintenance instructions, and help staff discover potential problems in a timely manner.

3、 Technical parameters (typical values)

Input voltage range: AC 220V or DC 24V (configured according to application requirements)

Input signal type: analog signal (voltage, current, frequency, etc.), digital signal (switch input)

Output signal type: standardized analog signal (such as 0-10V, 4-20mA), digital signal output

Operating frequency: 50Hz/60Hz (automatic adaptation)

Accuracy: Analog signal accuracy ± 0.1%, digital signal error ≤ 0.5%

Overload protection: supports short circuit protection, overcurrent protection, and overvoltage protection

Working temperature range: -10 ° C to+60 ° C

Size: Compliant with the 193X series standard plug-in card structure (approximately 25 × 15 cm)

4、 Application Fields

Power plant: used for monitoring and controlling generators to ensure the safe and stable operation of the generator system.

Wind power generation: Monitor and protect the generators of wind turbines to ensure power generation efficiency and equipment safety.

Ship control system: used for monitoring the operation of ship generators and optimizing the management of power systems.

Industrial automation: providing real-time monitoring and control for various generators in industrial production.

Military and emergency backup power supply: Ensure the reliability and continuity of power supply in emergency generator systems.

Product imag
