Product Details Introduction

Brief introduction

The GE 193X725ABG01 pulse generator is an important module in the GE 193X series, designed specifically for industrial automation, control systems, and signal processing applications. This module is used to generate accurate pulse signals and is widely used in fields such as motor control, sensor acquisition, and signal conditioning.

2、 Core functions

Accurate pulse generation: capable of generating high-precision pulse signals, supporting multiple pulse frequency and width settings to ensure stable signal output.

Pulse output control: Adjust the frequency, amplitude, or pulse width of the pulse output based on input conditions or external signals.

Signal synchronization: supports synchronous operation with other modules or devices, ensuring that all parts work together, especially suitable for complex control systems.

High frequency pulse output: suitable for high-speed control and detection applications, with pulse frequencies up to several hundred kHz.

External triggering function: supports external triggering signal input, used to control the timing of pulse occurrence.

Signal processing and adjustment: Equipped with a built-in signal adjustment circuit, it can amplify, attenuate, or filter the output pulse signal to meet different application requirements.

3、 Technical parameters (typical values)

Input voltage: AC 220V or DC 24V (can be configured according to system requirements)

Output signal type: pulse signal (adjustable frequency, adjustable width)

Output frequency: from a few Hz to several hundred kHz (specific range depends on model configuration)

Output waveform: square wave, pulse wave

Accuracy: Pulse frequency error ≤ 0.1%, pulse width error ≤ 0.5%

Overload protection: built-in short circuit, overcurrent, and overvoltage protection circuits

Working temperature range: -10 ° C to+60 ° C

Size: Compliant with the 193X series standard plug-in card structure (approximately 25 × 15 cm)

4、 Application Fields

Motor control: used for generating pulse signals in motor drive systems to ensure precise control of the motor.

Signal processing and regulation: providing precise timing control signals for various industrial automation systems.

Sensor application: Used for precision sensor data acquisition and signal transmission.

Measurement and testing equipment: Provide a stable signal source in testing and measurement systems for equipment calibration or data analysis.

Communication system: can be used for pulse signal generation in communication systems such as modulation and demodulation, timing control, etc.
