193X717AAG01 power module

193X717AAG01 power module

Product Details Introduction

Brief introduction

193X717AAG01 is a power module in the 193X series produced by GE, specifically designed to provide stable power supply for GE's industrial control systems, drive systems, or power generation control systems. This module is used to convert and regulate power sources, ensuring that the power requirements of various modules within the system are met, and providing protection functions.

2、 Main functions

Voltage conversion and regulation: Convert the main power supply (such as AC or DC) to the standard voltage required by the system, with common outputs of+15V, -15V, and+5V.

Current supply: Provides stable current output to meet the power needs of multiple control modules and sensors.

Overvoltage and overcurrent protection: Built in current and voltage protection circuits to prevent system damage caused by abnormal power supply.

Load regulation: It can automatically adjust the output voltage to adapt to load changes and maintain stable system operation.

Redundant design: Supports dual power input or redundant power configuration to improve system reliability and stability.

Overheating protection: Built in temperature sensor, real-time monitoring of module temperature to prevent faults caused by overheating.

3、 Technical parameters (typical values, reference purposes)

Input voltage: AC 220V or DC 24V (can be selected according to system requirements)

Output voltage:+15V, -15V,+5V (standard output)

Output current capability: 5A (depending on output voltage and load requirements)

Output power: approximately 75W (depending on configuration and load)

Efficiency: ≥ 85% (typical)

Overload protection: supports short circuit, overcurrent, and overvoltage protection

Working temperature: -10 ° C to+60 ° C

Installation method: Standard 193X plug-in card structure

Size: Complies with the 193X series standard size (approximately 25 × 15 cm)

4、 Application Fields

Industrial control system: used in various industrial automation equipment to ensure the normal operation of control boards, sensors, and actuators.

Drive system: provides stable power supply for variable frequency drive, high-power motor control system, etc.

Power plant control: providing power to control equipment in thermal, hydraulic, and wind power generation systems.

Power equipment: supplies power to control and protection devices in the distribution system.

Data center: used to provide regulated power supply to support the operation of computers and related equipment.

Product imag
