AMAT 0240-27279 Dual Laser Robot Module

AMAT 0240-27279 Dual Laser Robot Module

 Introduction

AMAT 0240-27279 dual laser robot module belongs to the wafer manipulator alignment accessories in semiconductor equipment.

Product Features:

1. Dual laser collaborative detection, high accuracy in wafer positioning and recognition, reducing wafer pickup offset

2. Anti cavity stray light interference, stable and reliable internal detection results of vacuum machine

3. Modular original structure, on-site disassembly and replacement without changing the original mechanical structure

4. Equipped with self checking status, it can directly output prompt signals in case of abnormal situations

5. Suitable for long-term continuous operation on production lines, suitable for high-frequency mechanical arm handling conditions of machines

Product Parameters:

1. Integrated dual laser sensing unit, matched with original mechanical arm communication interface

2. Support RCF alignment calibration of robotic arms to meet the requirements of wafer position calibration

3. Can withstand the normal operating temperature of equipment cabinets and adapt to the internal environment of the machine

4. Equipped with a local display operation panel, it allows for easy on-site debugging of alignment parameters

5. The electrical communication protocol is completely compatible with the entire system, without the need for additional modifications

Application fields:

1. AMAT Semiconductor Equipment Wafer Robot Position Calibration and Alignment

2. Etching equipment vacuum chamber wafer picking and placing positioning detection

3. Thin film deposition equipment wafer transfer robot calibration operation

4. Replacement of aging spare parts for the old machine's robotic arm laser detection unit

5. Alignment and debugging after semiconductor equipment maintenance, disassembly and repair

Overall, AMAT 0240-27279 ensures the accuracy of wafer handling by robotic arms and reduces fragment alarms, making it a critical component in the material transfer process of the machine.

Product imag
