Nikon 4T070-341-1 amplifier module, NSR-S620D lithography machine optical focusing mechanism dedicated power amplifier board.

Product Features:

1. The small signal gain is stable, driving the focusing actuator, and the dynamic response is sensitive

2. Built in overcurrent protection effectively suppresses instantaneous impact and protects optical components

3. Anti high frequency vibration inside the cabinet, long-term operation gain will not drift

4. Board slot direct installation, easy disassembly and assembly, no need to disassemble lens unit

5. Equipped with status monitoring, it can record abnormal operating conditions for easy review

Product Parameters:

1. Adapt to the back panel interface of the lithography machine and receive the focusing control signal issued by the main control

2. Perform power amplification on weak control signals and drive focusing actuators

3. Can withstand temperature fluctuations inside the cabinet and meet continuous production conditions

4. Real time feedback of the driving circuit status to the overall control system

5. Output corresponding status codes for faults to shorten on-site maintenance time

Application fields:

1. NSR-S620D lithography machine focusing servo circuit power drive

2. Exposure Optical System Focusing Mechanism Control Magnification

3. Replacement of spare parts for damaged servo boards inside the equipment

4. Renovation and repair of second-hand machinery with electronic components

5. Calibration and debugging of focusing servo circuit after equipment overhaul

The output quality of Nikon 4T070-341-1 directly determines the optical focusing response, affecting the imaging clarity and process yield of lithography machines
