Semitool 900T0097-507 I/O block unit

Semitool 900T0097-507 I/O block unit

 Introduction

Semitool 900T0097-507 I/O block unit, integrated wiring module for signal interaction of wet electroplating cleaning equipment.

Product Features:

1. Good channel isolation and protection to isolate signal interference caused by the process environment

2. Integrate multiple input and output channels, and unify the docking of valve groups and sensor signals

3. Corrosion resistant shell, suitable for workshop cabinet working conditions where chemicals evaporate

4. Modular assembly, plug-in installation, on-site maintenance does not require dismantling wires one by one

5. Channel failure independent feedback, single channel abnormality does not affect the operation of other channels

Product Parameters:

1. Match Semitool wet equipment native interface and wiring definition

2. Collect liquid level, valve, sensor status signals and forward them to the main control

3. Adapt to equipment cabinet temperature and humidity, withstand slight corrosion from chemical gases

4. Output switch signal to control pneumatic valve and actuator components

5. Channel abnormal output status signal, convenient for quickly locating point faults

Application fields:

1. Semitool electroplating cleaning machine on-site signal acquisition and conversion

2. Signal docking of wet process chamber solenoid valve and liquid level sensor

3. Old wet equipment I/O assembly aging and damaged spare parts replacement

4. Semiconductor wet process equipment renovation and maintenance supporting components

5. IO point verification and circuit debugging after machine maintenance

Semitool 900T0097-507 serves as an on-site signal relay hub, and its reliability directly determines the normal interaction of valve sensing signals in wet equipment.

Product imag
