JENOPTIK JOLD-210-CAXF-6A laser diode

JENOPTIK JOLD-210-CAXF-6A laser diode

 Introduction

JENOPTIK JOLD-210-CAXF-6A laser diode, fiber coupled high-power continuous output laser bar module.

Product Features:

1. High electro-optical conversion efficiency, the beam passes through fast axis collimation, and the output spot is uniform and stable

2. Microchannel water-cooled structure, high heat dissipation efficiency, and low thermal drift during long-term high-power operation

3. Fiber optic coupling output, anti-interference optical path, reducing spatial optical path offset loss

4. Resist current surges, adapt to equipment start stop cycles, and extend device service life

5. Standardized packaging, complete module replacement, no need to disassemble internal bar components

Product Parameters:

1. Continuous output power of 210W, matched with the corresponding operating wavelength of the band

2. Deionized water active water cooling, suitable for industrial equipment water cooling circuits

3. Equipped with fiber optic output, fixed numerical aperture, and regular output optical path

4. Can be connected to external current sources and receive drive control signals

5. Can provide feedback on the optical power related status to the equipment monitoring system

Application fields:

1. Semiconductor testing equipment laser light source unit core light-emitting device

2. Solid state laser and fiber laser pump source matching

3. Configuration of Light Source Modules for Industrial Laser Process Equipment

4. Replacement of laser light source spare parts due to aging and damage of production line

5. Optical equipment light source debugging and performance calibration

The luminescence quality of JENOPTIK JOLD-210-CAXF-6A directly determines the performance of the entire optical system and is related to the final results of detection and processing.
