Yaskawa JANCD-NIO30B-1 Robot Controller

Yaskawa JANCD-NIO30B-1 Robot Controller

 Introduction

#Yaskawa JANCD-NIO30B Robot IO Interface Board

1. Model: Yaskawa JANCD-NIO30P-1, internal IO interface board of Yaskawa robot controller

2. Undertake the external IO signal acquisition and output control of the robot control cabinet

3. Multiple digital input/output channels, connected to peripheral sensors and solenoid valves

4. Optoelectronic isolation circuit, isolates external interference, protects the main control unit

5. Receive peripheral switch signals and transmit them back to the robot's main control CPU

6. Output control signals to drive fixtures and peripheral actuators

7. Adapt to the native bus and timing protocol of Yaskawa Motoman robot

8. Hardware signal filtering to resist electromagnetic noise inside the control cabinet

9. Capable of channel fault detection, identifying short circuits and abnormal points

10. Industrial grade components, supporting long-term continuous production by robots

11. Onboard channel indicator light, visually viewing the on/off status of IO points

12. The parameters of the board are fixed with the robot program and can be directly called after replacement

13. Standard card slot, installed inside the robot controller chassis

14. Comes with original connectors to reduce on-site wiring faults

15. Widely used in Yaskawa robot systems for handling, welding, assembly, etc

In summary, the Yaskawa JANCD-NIO30B − 1 robot IO interface board serves as a carrier for signal interaction between the robot and peripheral devices, ensuring stable transmission and reception of external signals for the entire machine.

Product imag
