SANYO DENKI 65AA030VXR03 servo amplifier card

SANYO DENKI 65AA030VXR03 servo amplifier card

Product Details Introduction

SANYO DENKI 65AA030VXR03 is a compact servo amplifier card designed specifically for controlling small and medium power servo motors. The following will explain its core parameters, performance characteristics, adaptation scenarios, and practical points:

1、 Core specifications and electrical characteristics

Power adaptation: The rated output current is 3A, and the adaptive power range is about several hundred watts to 1.5 kW (specific needs to be matched with motor parameters), meeting the power control requirements of small automation equipment.

Power Supply and Control: Supports AC200-230V single-phase/three-phase input, compatible with pulse commands (position mode) and analog commands (speed/torque mode), and can be controlled through dip switches or software configuration.

Protection function: Built in multiple protections such as overcurrent, overvoltage, overload, motor overheating, encoder abnormality, etc., quickly cut off the output when a fault occurs to avoid equipment damage.

2、 Structural and installation advantages

Compact design: adopting a card structure, with a small volume (reference size: about 150 × 100 × 30mm), it can be directly installed on the DIN rail or panel of the equipment control cabinet, saving installation space.

Modular layout: power, control, and drive circuit partition design, high heat dissipation efficiency, and easy fault location and component replacement during later maintenance.

Convenient wiring: Adopting plug-in terminals, the interfaces of power lines, control lines, and encoder lines are clear and labeled, reducing the probability of wiring errors.

3、 Performance characteristics and adaptation scenarios

Precise control: Equipped with high-precision current loop and speed loop control algorithms, the position positioning accuracy can reach ± 0.01mm (with high-resolution encoder), suitable for equipment that requires precise positioning such as surface mount machines, small CNC machine tools, and precision conveyor belts.

Fast response: The current response bandwidth reaches kHz level, ensuring smooth motor start stop, acceleration and deceleration processes, reducing load shaking, and adapting to frequent start stop conditions (such as electronic component assembly equipment).

Strong compatibility: It can adapt to SANYO DENKI and other brands of small and medium power servo motors (motor parameters need to be matched), and can also seamlessly integrate with upper level devices such as PLCs and motion controllers.

Low noise and energy-saving: Adopting sine wave PWM driving technology, the operating noise is low (≤ 60dB), while reducing motor iron and copper losses, improving system energy efficiency.

SANYO DENKI 65AA030VXR03 Product imag

SANYO DENKI P20B13500HXSH6 Controller Module
