Product Details Introduction

SANYO DENKI P20B13500HXSH6 belongs to the Shanyang P2 series high-power AC servo motor. Common versions with the suffix "E" (such as P20B13500HXSH6E) focus on strong power output and stable transmission, adapting to the precision drive requirements of medium and large automation equipment. Combined with the same series parameters and market circulation information, its core details are summarized as follows:

Core specification parameters

Power and electrical parameters: Referring to the parameters of the similar model P20B1360HXSH6E in the same series, it can be inferred that the rated output power of the motor is approximately 6KW, compatible with a 200V AC power supply, with a rated speed of 3000 revolutions per minute, which can meet the continuous power output requirements under medium and heavy load conditions. As a P2 series model, it continues the characteristics of the PY2 servo drive adapted to this series, and can achieve precise speed and torque control with the help of the drive.

Mechanical structural parameters: From the perspective of the series universal design, its flange size is 130mm, which is a common large-sized flange specification for high-power servo motors and can ensure structural stability after installation. The overall body is heavy and suitable for industrial equipment that requires stable installation. The mechanical details such as output shaft size and length are consistent with the same series of 6KW level models, making it easy to use and replace accessories.

Series features and adaptation advantages

Performance characteristics: P2 series servo motors generally have high response characteristics. When paired with Shanyang high-resolution encoders, they can achieve high-precision position feedback, meeting the strict requirements for positioning accuracy of CNC machine tools, industrial robots and other equipment. At the same time, the structural design of this series of motors can adapt to frequent start stop working conditions, with smooth power output and reduced vibration problems during load operation.

Flexibility of adaptation: The PY2 series servo drive is compact in size, reduced by 40% -55% compared to the previous generation, and supports two installation methods: backplate and panel. It can reduce the installation space occupied by the combination of motor and driver, and also facilitate wiring and debugging operations during later maintenance.

Market Circulation and Application Scenarios

Circulation situation: This model and its suffix version are circulated on Alibaba and international industrial parts platforms, mostly sold in second-hand or brand new negotiated forms. The warranty period for second-hand models is usually 3 months, and the price of the new model is relatively high. For example, the price of the P20B1360HXSH6E series is as low as 5769.23 US dollars, while the price of the same second-hand model is as low as 576 US dollars. The price difference is greatly affected by the condition and functional integrity.

Typical applications: With a high-power output of 6KW, it is commonly used in spindle drives of CNC machine tools, transmission mechanisms of large packaging machinery, heavy-duty conveying units of semiconductor production equipment, and can also be adapted to heavy-duty joint drives of industrial robots, providing power support for high-precision and high stability operation of equipment.

SANYO DENKI P20B13500HXSH6 Product imag
