Product Details Introduction

1、 Product Overview

Atlas Copco PF4002-G-PB-HW is a high-performance intelligent tightening controller in the Power Focus 4000 series, integrating drive, power, control, and communication functions. This controller is used to manage Atlas Copco Tensor series power tools, supporting advanced tightening logic, data traceability, and industrial communication integration, and is suitable for high demand automated assembly environments.

Model meaning:

PF4002:4000 series, 2-level power control range (suitable for small and medium-sized torque tools)

G: Advanced version, supporting extended functionality and graphical control

PB: Integrated PROFIBUS communication interface

HW: Hardware Standard Version

2、 Technical Parameters (Core Summary)

Control methods: torque control, angle control, angle monitoring, multi-stage composite control

Adaptation tools: Atlas Copco series including Tensor STR, STB, EBL, ETX, etc

Number of supported programs: up to 999 independent tightening programs

Communication interfaces: PROFIBUS, Ethernet, USB, RS232, I/O (optional expansion)

Data function: Tighten data collection, storage, analysis, and real-time upload to MES

Installation method: Installation inside the control cabinet or embedded equipment panel installation

Extended support: Supports Tool Location, Focus Control, Barcode/RFID workpiece recognition functions

3、 Application Fields

1. Manufacturing of automobiles and new energy vehicles

High precision tightening process control for engine assembly, chassis, suspension, battery module, etc

Support data integration with MES system to achieve tightening task and VIN binding, workstation recognition, and graphic control process

2. Industrial automation production line

Used for robot tightening systems, workstation style tightening tables, and multi station collaborative control systems

Suitable for mixed production of multiple products and automatic program switching in flexible production lines

3. Rail transit and heavy machinery

Process control of high-strength connectors such as large structural components, wheelsets, hinges, etc

Capable of handling complex working conditions with high workloads and high stability requirements

4. Home appliances and electronics manufacturing

Small and medium-sized torque tightening scenarios, such as motor housing, panel assembly, bracket connections, etc

Fast workstation switching, visual status feedback, and flexible program scheduling

Product imag
