UNIOP ETOP30-4550 operation interface panel

UNIOP ETOP30-4550 operation interface panel

Product Details Introduction

UNIOP ETOP30-4550 is one of the UNIOP series human-machine interface (HMI) products under EXOR International in Italy. It is a high-performance industrial operation interface panel designed to provide human-machine interaction functions for various automation control systems.

The following is a detailed explanation without patterns:

1、 Product Name

UNIOP ETOP30-4550 operation interface panel

2、 Overview of Basic Functions

ETOP30-4550, as a universal touch screen HMI, has the following functions:

Real time display and operation

Display production status, alarm information, trend charts, etc

Users can adjust parameters, control processes, and manage equipment through the touch screen

Multi protocol communication

Support mainstream PLC communication protocols, such as:

Siemens S7, Allen Bradley, Mitsubishi, Omron, Modbus RTU/TCP, etc

Can be used as a master or slave station to connect with the control system

Alarm and Formula Management

Built in alarm processing function, supporting event recording and historical query

Can download and upload recipe parameters to achieve batch switching

Graphic interface development

Support EXOR dedicated development environment JMobile Studio for project creation, animation, scripting, data processing, etc

3、 Technical specifications (model ETOP30-4550)

Project parameters

Display screen type TFT color LCD display screen

Screen size 4.3-inch WQVGA (480 × 272 pixels)

Touch Control Method: Resistive Touch Screen

Backlight lifespan ≥ 20000 hours (adjustable brightness)

CPU ARM Cortex-A8 600MHz or above

Memory 128 MB Flash+64 MB RAM (specific version may vary)

Communication interface 1 x Ethernet port, 1 x RS232/RS485 serial port

USB interface 1 x USB Host

Operating System Linux Embedded System

Input power supply 24V DC (± 20%)

Protection level front panel IP66 (when installed correctly)

Installation method: Panel installation, compatible with standard industrial control cabinets

Working temperature -10 ° C to+60 ° C

Storage temperature -20 ° C to+70 ° C

Product imag
