HONEYWELL 51451397-501 Analysis Output Module

HONEYWELL 51451397-501 Analysis Output Module

Product Details Introduction

HONEYWELL 51451397-501 Analysis Output Module is a critical component in Honeywell process control systems, belonging to the I/O module in the architecture of the Expert PKS/TDC 3000/C300/TPS system. This module is mainly used to output analysis data (such as gas and liquid composition analysis results) from the control system, and is commonly used for the integration of analytical instruments and data transmission in process control.

1、 Basic Product Information

Brand: HONEYWELL

Model: 51451397-501

Name: Analytical Output Module

Applicable systems: TDC 3000, Expert PKS, TPS, C300 or certain legacy control systems

2、 Functional Features

Analysis data output: transmit processed data from analytical instruments (such as gas analyzers, liquid chromatographs, infrared detectors) to the control system;

Analog output capability: outputting standard current/voltage signals, such as 4-20 mA, for driving actuators or transmitting data to the upper computer;

Supports multiple output channels: typically with 2-8 analog outputs that can be independently configured;

High precision and stability: designed for critical process control applications, with high requirements for precision and long-term stability;

Strong system integration capability: seamless integration with HONEYWELL's controllers, control stations, and engineering stations (EWS);

Redundancy support: Can be configured as hot backup or dual module redundancy to improve reliability;

Status and fault diagnosis function: supports module self status monitoring and output channel fault alarms.

3、 Typical technical parameters (estimated values, for reference only)

Number of analog output channels: 4 or 8 (to be confirmed)

Output type: 4-20 mA or 0-10 V

Output accuracy: ± 0.1% FS (depending on the system)

Isolation method: Isolation between channels, power supply and output

Power supply: 24V DC (usually powered by the system backplane)

Working temperature range: 0 ℃~+60 ℃

Installation method: System slot installation (insert HPM or C300 control rack)
