193X709AAG01 High Power Universal Amplifier
Product Details Introduction
GE 193X709AAG01 High Power Universal Amplifier Technical Data
Product model: 193X709AAG01
Product Name: High Power General Amplifier
Manufacturer: General Electric (GE)
Series: 193X series industrial control board
Functional classification: High power signal amplifier, suitable for various industrial applications
Application areas: industrial automation, generator control, energy management, equipment drive, etc
1、 Product Features
The GE 193X709AAG01 high-power general-purpose amplifier is designed to provide high-power signal amplification and processing capabilities for industrial systems. It can enhance the amplitude of input signals, drive various electrical loads, and is widely used in industrial control systems, power generation equipment, sensor driving, and motor control. This amplifier has high efficiency, stability, and high power processing capability, ensuring long-term reliable operation under high load conditions.
Main functions:
High power signal amplification: Provides high-performance signal amplification to ensure that the system can drive larger loads.
Multi channel input/output: Supports multiple input signals and can process multiple signal channels simultaneously, providing higher flexibility.
Stable output power: It can maintain a stable output signal even under high load conditions, ensuring the stable operation of the system.
Efficient thermal management: Designed with excellent heat dissipation performance to ensure that it will not overheat during high-power operation.
Signal conditioning: Provides gain adjustment of input signals to meet the needs of different application scenarios.
Anti interference design: It has strong anti electromagnetic interference ability and is suitable for complex industrial environments.
2、 Main technical parameters
Parameter item description
Input signal type: analog signal, usually voltage or current input
The output power has a high power output capability and supports driving high-power loads
The gain range supports a wide range of gain adjustments, which can be adjusted according to application requirements
Frequency response broadband response, suitable for applications in multiple frequency ranges
The applicable voltage range of the power supply is usually 24V DC or 48V DC (depending on system requirements)
High efficiency and low power consumption design, providing maximum power output while reducing energy consumption
Working temperature range -40 ° C to+85 ° C, suitable for various industrial environments
Signal isolation: Input and output signals are electrically isolated to avoid signal interference
The card size conforms to the standard size of GE 193X series
The communication interface supports multiple industrial communication protocols, such as Modbus, Profibus, etc
Fault detection and protection function with built-in protection circuit, supporting overload, over temperature and other protection functions
Product imag
