193X706AAG02 amplifier card

193X706AAG02 amplifier card

Product Details Introduction

GE 193X706AAG02 amplifier card technical data

Product model: 193X706AAG02

Product Name: Amplifier Card

Manufacturer: General Electric (GE)

Series: 193X series industrial control board

Function classification: Signal Amplification and Gain Adjustment Module

Application areas: Industrial automation systems, data acquisition, process control, etc

1、 Product Features

The GE 193X706AAG02 amplifier card is a module used to increase input signal amplitude and provide signal gain. It amplifies the weak input signal so that it can be accepted by other downstream devices or control units in the system. This card is widely used in systems that require signal gain and amplification, such as industrial automation control, sensor signal processing, data acquisition systems, etc.

Main functions:

Input signal amplification: Amplify low amplitude analog signals to meet the input requirements of downstream devices.

Gain adjustment: Provides different gain options to adapt to various input signal conditions.

Signal stability: Improve signal stability, reduce noise interference, and ensure precise control.

Electrical isolation: To prevent interference from high voltage or electrical noise, provide electrical isolation between input and output.

2、 Main technical parameters

Parameter item description

The input signal type is analog signal, such as voltage, current signal, commonly 0-10V, 4-20mA, etc

The output signal type is an amplified analog signal, usually ranging from 0-10V or other standard voltage outputs

Amplification gain adjustable gain, usually providing multiple gain setting options such as 1x, 10x, 100x, etc

Input/output isolation provides electrical isolation between input and output, preventing the transmission of electrical noise and interference

Power requirement ± 15V DC or 24V DC, according to the system power standard

Signal bandwidth is suitable for broadband signal amplification in industrial applications, ensuring accurate signal transmission

The working temperature range is usually -40 ° C to+85 ° C, suitable for various industrial environments

Installation method plug-in card, compatible with GE 193X series control rack or control system framework

The interface type generally adopts terminal connection or metal pin interface, which is used to connect external sensors and devices

Card size standard GE plug-in module size, in accordance with the standard format of 193X series cards

Product imag
