TEL HTE-OV5-A-11 Input/Output Module

TEL HTE-OV5-A-11 Input/Output Module

 Introduction

TEL HTE-OV5-A-11 Input/Output Module

1. TEL HTE-OV5-A-11 is a switch IO board specifically designed for semiconductor process equipment at Tokyo Electronics

2. Equipped with photoelectric isolation circuit, it isolates high-voltage surges and electromagnetic interference on site, protecting the main control board

3. Collect input signals from various on-site switches such as chamber door locks, vacuum pressure switches, and limit sensing

4. Output level signal to drive on-site execution components such as solenoid valves, cylinders, indicator lights, etc

5. Original factory rack direct insertion installation, easy to plug and replace, no additional modification required for installation and alignment

6. Independent channel signal filtering, filtering instantaneous clutter jitter, avoiding signal false triggering

7. Equipped with overcurrent and short-circuit hardware protection, single channel faults will not affect the entire module circuit

8. Exclusive internal bus for supporting equipment, stable data transmission and reception, and minimal packet loss during operation

9. The terminal block buckle is firmly locked, and the machine is not prone to loose wiring and poor contact under long-term vibration conditions

10. Suitable for use in dust-free workshops, with an internal dust-proof structure that prevents dust from accumulating and causing short circuit faults

11. Tolerate the normal working temperature rise of the equipment and ensure that the performance parameters do not drift during long-term uninterrupted operation

12. Each signal channel is independently wired, and the degree of signal interference between channels is extremely low

13. Built in hardware self-test program, can report real-time alarms to the upper computer for line abnormalities and channel failures

14. Solid soldering process for electronic components, low failure rate for semiconductor production lines operating continuously 24/7

15. The whole machine program does not need to be re debugged, and the original supporting equipment can be directly put into operation on the machine

TEL HTE-OV5-A-11 is mainly used for on-site status acquisition and basic actuator control of etching and thin film deposition equipment.
