TEL 2L81-050105-V2 Printed Circuit Board

TEL 2L81-050105-V2 Printed Circuit Board

 Introduction

TEL 2L81-050105-V2 Printed Circuit Board

1. Supporting TEL semiconductor process equipment to achieve signal acquisition and instruction transmission of gas path components

2. 2L81-050105-V2 line partition wiring, isolating strong and weak electricity, reducing signal crosstalk

3. High performance substrate with excellent temperature resistance, suitable for long-term continuous operation environment of control cabinets

4. All surface mount components are factory assembled and undergo power on aging testing to screen for potential hazards before leaving the factory

5. 2L81-050105-V2 plug-in terminal is gold-plated to suppress oxidation and maintain stable conductivity

6. Built in surge protection circuit to withstand instantaneous voltage surges and protect onboard components

7. Multi layer PCB structure with built-in electromagnetic shielding to reduce the impact of RF interference

8. Accurate positioning of holes, seamless assembly with equipment racks, easy installation and alignment

9. 2L81-050105-V2 multi-channel signal channels are processed in parallel to meet the linkage requirements of the pneumatic control system

10. Board surface protective coating, isolating dust and trace corrosive gases from corroding the circuit

11. Support real-time feedback on the working status of the channel, making it convenient for operation and maintenance to quickly locate the fault location

12. 2L81-050105-V2 standard interface layout, time-saving disassembly and maintenance, and reducing downtime

13. Stable signal response speed ensures accurate timing of coordinated control of valves and flow meters

14. Following TEL's original electrical design standards, boards of the same model can be directly interchanged for use

15. Unified performance parameters for mass production, spare parts replacement does not require large-scale parameter debugging

The TEL 2L81-050105-V2 printed circuit board is a dedicated circuit board for the gas control unit of semiconductor machines, used for signal scheduling in gas control systems and widely used for replacing equipment failure spare parts.
