TEL 2L81-050096-V2 gas board PCB

TEL 2L81-050096-V2 gas board PCB

 Introduction

TEL 2L81-050096-V2 gas board PCB

1. Adapt to TEL etching deposition equipment gas box unit, control MFC and solenoid valve signal interaction

2. 2L81-050096-V2 accurately transmits gas flow control signals to ensure stable process gas ratio

3. Multi layer PCB substrate, partitioned isolation of power circuits and weak analog signals to reduce crosstalk

4. Original factory component surface mount welding, completed power on aging screening test before leaving the factory

5. 2L81-050096-V2 connector contacts are gold-plated, providing long-term continuous operation with anti-oxidation and stable conductivity

6. Built in surge and short circuit protection circuit to prevent abnormal voltage from damaging pneumatic components

7. The board is heat-resistant and suitable for long-term working environments in enclosed cabinets and clean workshops

8. Optimization of circuit layout to effectively resist cavity RF electromagnetic interference

9. High precision machining of positioning holes, precise alignment and assembly with the air box frame

10. 2L81-050096-V2 is equipped with channel status feedback, making it easy to quickly troubleshoot air circuit control faults

11. Standard signal terminal interface, convenient on-site disassembly and maintenance, reducing downtime

12. Support parallel regulation of multiple gas channels to meet the complex process gas supply logic requirements

13. The board surface is coated with a protective layer to prevent dust and trace corrosive gases from corroding the circuit

14. Following TEL's original electrical specifications, the same model 2L81-050096-V2 can be directly interchanged

15. Batch electrical parameters have excellent consistency, and spare parts replacement does not require complex debugging

TEL 2L81-050096-V2 gas board PCB is a dedicated control circuit board for semiconductor process equipment gas boxes, responsible for gas flow and valve drive signal processing. It is a commonly used maintenance spare part for etching and thin film equipment.
