TEL BX80-000063-V1 Controller

TEL BX80-000063-V1 Controller

 Introduction

TEL BX80-000063-V1 Controller

1. Compatible with Tokyo Electronic Semiconductor Equipment, serving as the central processing control unit for the entire machine

2. Multi port and serial interface configuration to achieve collaborative data communication and interaction among multiple modules

3. TEL BX80-000063-V1 has powerful real-time computing capabilities and accurately executes the entire process timing sequence

4. Built in hardware fault diagnosis system, real-time collection of operational status information of each submodule

5. Integrated electrical isolation and surge protection to resist hardware damage caused by grid fluctuations

6. TEL BX80-000063-V1 is native and compatible with TEL device communication protocols, and can interface with various IO and driver boards

7. Optimize the design of heat dissipation ducts to support long-term uninterrupted high load operation in clean rooms

8. Modular chassis structure, easy disassembly and assembly of internal boards, reducing downtime for maintenance

9. TEL BX80-000063-V1 large capacity local storage, stable storage of multiple sets of wafer process formulas

10. Improve data verification mechanism to reduce instruction transmission packet loss and signal distortion issues

11. Support remote status monitoring, facilitating operation and maintenance personnel to view process conditions online

12. TEL BX80-000063-V1 Strong and Weak Current Line Partition Layout to Reduce Signal Interference

13. Support firmware iteration and upgrade, continuously update and optimize software versions for matching devices

14. The body status indicator lights are complete, and communication and hardware abnormal points can be quickly located

15. After a long period of online aging testing at the factory, the stability of the entire machine's operation is guaranteed

TEL BX80-000063-V1 controller is widely used in the main control chassis unit of TEL etching, coating and developing equipment

Product imag
