EATON 40071361238 Controller Module

EATON 40071361238 Controller Module

 Introduction

The EATON 40071361238 controller module is a CGLine+series emergency lighting system web main control unit, used for centralized control of fire emergency lighting fixtures in industrial plants and clean workshops

1. Built in embedded web server, directly connected to the computer locally without the need for additional upper level software

2 supports 4 lighting buses, with a maximum of 200 emergency lighting fixtures mounted on a single circuit

Equipped with STAR bus technology, it can monitor the status of lighting fixtures without the need for a separate data cable

4. Automatic inspection of lighting fixtures, regular self inspection of discharge duration and brightness, and retention of records

5. Store complete test logs for more than 4 years, facilitating compliance acceptance and fault tracing

6-zone control function, capable of starting, stopping, and blocking emergency lighting circuits separately by area

7 levels of password permission management, distinguishing operation and maintenance personnel from administrator operation permissions

Equipped with dual communication interfaces of Ethernet and USB, supporting program upload and remote monitoring

9DIN standard rail installation, easy to disassemble and fix control cabinet

10IP20 protective flame-retardant shell, suitable for indoor working conditions in semiconductor dust-free workshops

11 wide temperature operating range -20 ℃~60 ℃, stable operation in high and low temperature environments

12 Short circuit, overcurrent, and reverse multiple circuit protection to prevent lamp circuit burnout

13 real-time fault indicator lights, quickly locate the points of disconnection, undervoltage, and failure of the lighting fixtures

14 compatible with LED, halogen and other types of emergency light sources, switch between constant/non maintenance lighting modes

15 can be linked with building PLC and fire control host to achieve automatic switching of emergency lighting for fire alarm

EATON 40071361238 controller module is centrally monitored for stability and easy operation and maintenance, suitable for the entire emergency lighting automation control system in factories and semiconductor clean rooms

Product imag

ontroller Module
