SANYO DENKI Q2AA08100DXP5B servo motor

SANYO DENKI Q2AA08100DXP5B servo motor

Product Details Introduction

SANYO DENKI Q2AA08100DXP5B is an AC servo motor in the Sanyo Q series that is suitable for small and medium power scenarios. It is known for its high cost-effectiveness and stable output, and is widely used in lightweight automation equipment. The following are its core features and practical information:

This model belongs to the Shanyang Q2AA series servo motor, with a rated power corresponding to 800W level and stable torque output, which can meet the power requirements of labeling machines, small conveyor belts and other equipment.

Built in 2500 line incremental encoder with high position feedback accuracy, coupled with servo drive to achieve 0.01mm level positioning control, suitable for precision assembly scenarios.

Adopting a low inertia design, the response speed of starting and braking is fast, which can reduce action delay and improve work efficiency in equipment that requires frequent start stop.

The body protection level reaches IP65, the shell has good sealing, can resist dust and a small amount of liquid splashing, and is suitable for long-term operation in dusty environments such as workshops.

The adapted voltage is AC200V, compatible with industrial general power supply systems, and does not require additional transformer equipment for wiring, making installation convenient.

During operation, the noise level is below 60 decibels, and the vibration amplitude is small, which can reduce the overall operating noise of the equipment and improve the operating environment.

Often used in conjunction with Shanyang RS series and PY series servo drives to form a complete drive system, it is widely used in automated production lines such as electronic assembly and food packaging.

The motor shaft end adopts a standard keyway design, which can directly adapt to transmission components such as couplings and synchronous wheels without the need for customized special connectors.

Weighing approximately 3.5kg and compact in size, it can be installed inside devices with limited space, meeting the layout requirements of miniaturized equipment.

The market has sufficient supply of accessories, making it easy to replace vulnerable parts such as bearings and encoders. Daily maintenance only requires regular inspection of connecting wires and cleaning of surfaces, resulting in lower costs.

Conclusion: The above content covers the performance parameters, adaptation scenarios, and maintenance points of SANYO DENKI Q2AA08100DXP5B servo motor, which can provide practical reference for the selection and use of power components in lightweight automation equipment

SANYO DENKI Q2AA08100DXP5B Product imag
