Sanyo Denki P10B13150BXAT0 servo motor

SANYO DENKI  P10B13150BXAT0 servo motor

Product Details Introduction

Micron level positioning accuracy: As a classic model of the P10 series, P10B13150BXAT0 is equipped with a high-resolution incremental encoder, coupled with fully closed-loop feedback control, the positioning error can be controlled at the micrometer level, and can achieve ultra fine motion execution in PCB drilling machines, precision surface mounting machines and other equipment.

High torque density output: adopting optimized electromagnetic winding design to achieve strong torque output in a compact body, with small torque fluctuations during low-speed operation, suitable for scenarios requiring constant torque drive such as CNC machine tool feed axes and small robot joints.

Wide range speed adaptation capability: The speed adjustment range covers low-speed heavy load to high-speed light load conditions, with a maximum speed of over 3000r/min. Combined with fast response characteristics, it can meet the switching needs of packaging machinery, textile equipment and other multi speed ranges.

Strong drive compatibility features: Perfectly compatible with Q series (such as QS1A15AP0XXXXS) and P series servo drives of the same brand, seamless linkage can be achieved without additional debugging, especially when upgrading old equipment, the original P1 series motor can be directly replaced, greatly reducing adaptation costs.

Low noise and stable operation design: Through rotor dynamic balance optimization and low friction bearing selection, the operating noise is below 60dB, the vibration amplitude is controlled within 0.1mm, and with efficient heat dissipation ducts, it can achieve 24-hour continuous and stable operation.

Convenient debugging and operation: Supports micro motion testing in conjunction with the driver, allowing for motor performance testing without the need to connect to higher-level devices. With the parameter storage function of the driver, standardized debugging of batch devices can be quickly achieved.

Full dimensional safety protection: Equipped with overload, overcurrent, and overheating protection modules, it automatically cuts off the output when the load exceeds 150% of the rated value. At the same time, it has an IP54 protection level and can adapt to dusty environments such as machine tool workshops and electronic factories.

Wide area industrial scenario adaptation: With balanced performance, it is widely used in semiconductor packaging equipment, medical testing instruments, automated assembly lines and other fields. It is not only the preferred model for new equipment matching, but also the benchmark replacement for Japanese old equipment maintenance.

SANYO DENKI P10B13150BXAT0 Product imag
