SANYO DENKI E685000VCE1 AC servo motor

SANYO DENKI E685000VCE1 AC servo motor

Product Details Introduction

The SANYO DENKI E685000VCE1 AC servo motor is equipped with a high-resolution absolute value encoder, which does not require origin regression operation. The position feedback accuracy can reach micrometer level, and it can accurately adapt to scenarios with strict positioning requirements such as semiconductor packaging and precision instrument assembly.

As a high-performance model of the E68 series, the E685000VCE1 adopts a high magnetic density rare earth permanent magnet design, with strong and stable rated torque output, suitable for medium and high power range operation requirements, and can provide continuous power support for heavy-duty automation equipment (such as large handling robots).

E685000VCE1 is compatible with three-phase wide AC power supply and can operate stably within the voltage fluctuation range of 200-240V. It is suitable for industrial power grid environments in different regions and reduces the impact of voltage fluctuations on equipment operation.

For high-speed operation scenarios, E685000VCE1 has optimized the motor rotor dynamic balance structure and winding heat dissipation design. It has high speed stability during high-speed operation and can quickly dissipate heat, avoiding the impact of high temperature on motor performance. It is suitable for high-speed sorting, precision machining and other working conditions.

The E685000VCE1 has excellent compatibility with SANYO DENKI 67ZA series and PY2 series servo drives. It can quickly complete system debugging through the automatic parameter matching function of the drive, reducing the time by more than 50% compared to traditional debugging processes and simplifying integration steps.

E685000VCE1 adopts a fully sealed motor housing design with a protection level of IP54, which can effectively resist dust, oil stains, and slight liquid splashes, and is suitable for multi pollutant environments such as mechanical processing workshops and automotive parts production lines.

The E685000VCE1 supports seamless switching between three control modes: position, speed, and torque. It can flexibly adjust the control mode according to different job requirements and adapt to diverse application scenarios such as material transfer, precision polishing, and assembly positioning.

Built in multiple protection mechanisms, E685000VCE1 has overcurrent, overheating, overvoltage, and locked rotor protection functions, which can monitor the motor operation status in real time and quickly cut off the output in case of abnormalities, avoiding damage to the motor and related equipment and improving operational safety.

Key components such as bearings and commutators are made of imported high-strength wear-resistant materials. After more than 100000 hours of reliability testing, E685000VCE1 has a long fault free operation time, reducing equipment maintenance frequency and lowering enterprise operation and maintenance costs.

Optimized electromagnetic shielding design, E685000VCE1 operates with electromagnetic radiation far below industry standards, without causing signal interference to surrounding precision sensors, PLC control systems, and other electronic devices, ensuring stable operation of the entire automation system.

The installation dimensions of the motor follow international standardized design. E685000VCE1 can directly replace servo motors of the same specifications from other brands without modifying the equipment installation structure, simplifying the process of upgrading and renovating old equipment, and reducing renovation costs.

SANYO DENKI  E685000VCE1 Product imag
