SANYO DENKI Q2AA08100DSX5X servo motor

SANYO DENKI Q2AA08100DSX5X servo motor

Product Details Introduction

The SANYO DENKI Q2AA08100DSX5X servo motor is equipped with a high-resolution incremental encoder, which has high position feedback accuracy and positioning error can be controlled at the micrometer level. It can accurately meet the precision positioning requirements of automation equipment and is suitable for electronic component assembly, precision testing and other scenarios.

As a representative model of the Q2AA series, Q2AA08100DSX5X adopts optimized motor winding and magnetic circuit design, stable rated torque output, and can adapt to the operation requirements of the 800W power range, providing continuous and strong power support for small and medium-sized automation equipment.

Q2AA08100DSX5X is compatible with three-phase AC power supply, with an energy conversion efficiency that is more than 6% higher than traditional servo motors. It can effectively reduce equipment energy consumption during long-term operation, in line with the green and energy-saving production concept in the industrial field.

For low-speed operation scenarios, Q2AA08100DSX5X has optimized torque fluctuation control technology. During low-speed operation, the torque is stable and the vibration amplitude is small, which can significantly improve the machining accuracy of the equipment in low-speed operation scenarios such as fine polishing and carving.

The Q2AA08100DSX5X has strong compatibility with SANYO DENKI 67ZA series and PY2 series servo drives. It can quickly complete parameter matching through the automatic tuning function of the drive, greatly reducing system debugging time and simplifying the automation system integration process.

Q2AA08100DSX5X adopts a compact body design, which reduces the volume by about 12% compared to traditional servo motors of the same power. It can be flexibly laid out in scenarios where equipment installation space is limited, effectively saving cabinet installation space.

The motor housing has undergone special anti-corrosion and wear-resistant treatment, and Q2AA08100DSX5X can adapt to slight dust and humidity changes (relative humidity ≤ 90%) in industrial environments, improving the adaptability and service life of the motor in complex environments.

The Q2AA08100DSX5X supports the free switching of three control modes: position, speed, and torque. It can flexibly adjust the control mode according to the needs of different application scenarios, and is suitable for diverse work scenarios such as packaging machinery, small CNC machine tools, and material conveying equipment.

Equipped with comprehensive overheating and overload protection devices, Q2AA08100DSX5X can monitor the motor's operating temperature and load situation in real time. When the temperature is too high or the load exceeds the rated range, the protection mechanism will be automatically triggered to prevent motor damage due to faults.

Key components such as bearings and rotors are made of high-strength and wear-resistant materials. After rigorous reliability testing, Q2AA08100DSX5X has a fault free operation time of over 15000 hours, reducing equipment maintenance frequency and operation costs, and minimizing production downtime losses.

During operation, the electromagnetic radiation is low, and Q2AA08100DSX5X will not cause signal interference to surrounding precision sensors, control systems, and other electronic devices, ensuring the stable operation of the entire automated production line.

SANYO DENKI  Q2AA08100DSX5X Product imag

SANYO DENKI  Q2AA08100DSX5X Controller Module
