TOYOTA PRS-3140C positioning attachment board

TOYOTA PRS-3140C positioning attachment board

Product Details Introduction

product overview

TOYOTA PRS-3140C positioning add-on board is an extended functional module specifically designed for automation control systems, mainly used to achieve high-precision positioning control and position detection. This module is typically used in conjunction with a main control board or motion control system to provide precise position data support for industrial robots, automated production lines, and precision assembly equipment. Its design aims to improve the repeated positioning accuracy and dynamic response speed of the equipment, ensuring the stability and consistency of the production process.

Technical parameters (example, specific values need to be confirmed according to the device version)

Input signal type: Supports position detection signals such as encoders, photoelectric sensors, magnetic switches, etc

Resolution: up to micrometer level (depending on the accuracy of the configured sensor)

Interface type: high-speed digital interface, standard industrial communication port (such as RS-422, CAN or dedicated bus)

Response time: millisecond level real-time processing capability

Working voltage: DC 5V/12V (depending on design)

Working environment: -10 ℃~+55 ℃, anti vibration and dust-proof design

Application scenarios

Industrial robot positioning

Accurate positioning control for end effectors of articulated and Cartesian robots

Realize precise path execution in welding, spraying, handling and other processes

Automated assembly line

Real time detection and adjustment of workpiece position

Ensure assembly accuracy and reduce quality defects caused by positional errors

Precision machining equipment

Applied to high-precision positioning equipment such as CNC machine tools, laser cutting, precision drilling, etc

Improve machining consistency and dimensional accuracy

Conveyor and Sorting System

Realize dynamic position capture on high-speed conveyor belts

Support automatic sorting and fixed-point parking of materials

Product imag
