Novellus Systems 03-283968-00 Vector Board

Novellus Systems 03-283968-00 Vector Board

Product Details Introduction

The Novellus Systems 03-283968-00 Vector Board is a specialized signal distribution and integration interface board used in Novellus semiconductor manufacturing equipment. As a high-density signal bridging platform, this module undertakes complex signal integration, relay, distribution, and isolation conversion tasks between multiple subsystems, and is widely used in process control systems for CVD, ALD, PVD, and other equipment.

1、 Basic Information

Project Content

Product Name: Vector Interface Board

Model 03-283968-00

Manufacturer Novellus Systems Inc. (now Lam Research)

Component type control/I/O signal centralized board, high channel interface module

Application signal summary, relay transmission, module interconnection and allocation

2、 Core functions

Functional category description

Signal relay and centralized management of signals from multiple controllers/actuators/sensors

Channel distribution distributes the main control signal to target modules (such as heaters, vacuum valves, MFCs, etc.) according to their functions

Interface conversion TTL ↔  CMOS、RS-232/485  ↔  Serial/parallel interface protocol conversion

Electrical isolation protection board for onboard optocouplers, surge protection, TVS suppressors, anti misconnection circuits, etc

Multi channel parallel processing supports simultaneous operation of tens to hundreds of channels, adapting to the control requirements of complex process systems
