WOODWARD 5503-282 Controller Module

WOODWARD 5503-282 Controller Module

Product Details Introduction

The WOODWARD 5503-282 controller module is a high-performance controller module provided by Woodward for industrial power equipment such as large engines, gas turbines, or generator sets. It is typically used to achieve precise speed control, load sharing, synchronization, and remote communication functions.

1、 Basic Product Information

Model: 5503-282

Product type: Controller module (may be an extension or specialized model of Woodward 723, 2301D, or MicroNet series)

Application objects: Gas/diesel engines, turbines, generator sets, compressor control systems

2、 Core functional features

Function Description

Engine speed control provides precise PID closed-loop speed regulation, suitable for generator grid connection and islanding operation

Load distribution and synchronization support parallel operation, load distribution (kW), reactive power distribution (kVAr) and other functions

Strong communication capability supporting industrial protocols such as Modbus, CANopen, RS-485, Ethernet, etc. (depending on version)

Remote monitoring and configuration can be achieved through Woodward's tool software (such as Toolkit, Monitor) for remote configuration and real-time monitoring

High reliability and safety industrial grade design, suitable for operating in harsh environments, supporting redundancy and self diagnostic functions

Flexible I/O expansion provides multiple analog/digital input/output channels, making it easy to integrate with sensors and actuators

3、 Typical technical parameters (reference)

Project parameters

Power input 18~32 VDC (usually 24V)

Analog input 0-5 V, 0-10 V, 4-20 mA (depending on module configuration)

Analog output 4-20 mA or PWM (for driving actuators)

Digital input switch input, multi-channel

Digital output relay or open collector electrode output

Communication interface RS-232/RS-485/CAN/Ethernet

Working temperature range -40 ° C to+70 ° C (industrial grade)

The protection level is usually IP20 (installed inside the control cabinet)
