193X707AAG01 motor on-site control card

193X707AAG01 motor on-site control card

Product Details Introduction

Technical Data of GE 193X707AAG01 Motor Field Control Card

Product model: 193X707AAG01

Product Name: Motor Field Control Card

Manufacturer: General Electric (GE)

Series: 193X series industrial control board

Function classification: Motor Control and Field Regulation module

Application areas: Industrial automation, motor control, process control systems, etc

1、 Product Features

The GE 193X707AAG01 motor field control card is mainly used in motor drive systems to directly control the on-site operation of the motor, adjust the motor's speed, power output, start stop status, etc. This card is suitable for systems that require real-time control of motors or electric motors, and can provide efficient motor control and regulation functions to ensure the stability and accuracy of motor operation.

Main functions:

Motor control: Implement functions such as start stop control, speed regulation, and current monitoring of the motor to ensure smooth operation during load changes.

On site adjustment: By directly connecting with the on-site control interface of the motor, the operating parameters of the motor can be adjusted in real time.

Load monitoring: Monitor the load status of the motor, including current, voltage, temperature, etc., and adjust the control strategy according to demand.

Overload protection: When the motor is overloaded or in an abnormal state, it automatically stops or alarms to prevent equipment damage.

Speed regulation function: supports precise adjustment of motor speed to adapt to different working conditions and load requirements.

2、 Main technical parameters

Parameter item description

Control methods include analog signal regulation (such as current and voltage) and digital signal input control (such as switch input)

Motor types are suitable for various types of motors such as AC motors, DC motors, synchronous motors, etc

Input signal type control signal (switch signal, analog voltage signal, etc.)

Output signal type motor control signal, such as regulating voltage, current or frequency signal

Power requirement ± 15V DC or 24V DC (depending on actual system power requirements)

Load current monitoring supports current sensor input to monitor motor operating status and load conditions

Environmental temperature range -40 ° C to+85 ° C, suitable for industrial environments

Card size standard GE plug-in card module size, in accordance with the 193X series format

Installation method: plug-in card, compatible with GE 193X series control rack

The communication protocol supports Modbus, Profibus, or other industrial protocols

The working frequency range supports wideband input and adapts to various industrial control requirements

Product imag
