IS215UCVEH2A controller card

IS215UCVEH2A controller card

Product Details Introduction

IS215UCVEH2A controller card

product description

IS215UCVEH2A is an embedded controller card designed by General Electric (GE) for its Mark VIe control system. This module integrates industrial computing functions for controlling gas turbines, steam turbines, and other large mechanical equipment in power plants. Its main function is to serve as the central processing unit of the system, implementing logical operations, communication management, and equipment control

Core functions

Central control board computer form operation control software executes control logic

Data collection integration, communication between data bus interface and IO module to obtain system status

Network communication is equipped with multiple communication interfaces, including Ethernet serial port and system bus communication

Synchronization management and command scheduling between various modules within the control system

Diagnosis and real-time logging of system operation status and fault information for remote diagnosis

Main characteristics

Industrial motherboards based on embedded processors can run real-time operating systems such as VxWorks or QNX

Equipped with built-in memory for local caching of operational data

Equipped with dual Ethernet ports, serial interface, USB interface, and system bus connector

Support cold start, hot start, and remote maintenance modes

Directly compatible with the control module in the Mark VIe control system and can be inserted into the UCSA bracket for use

technical specifications

Power input DC 5V

The operating environment temperature range is from minus 20 to 70 degrees Celsius

Seismic and anti-interference design suitable for industrial grade harsh environments

Standardized plug-in card structure for easy on-site quick replacement

The onboard memory and storage configuration depend on the specific version. H2A versions generally have higher memory capacity

Typical applications

Applied to GE Mark VIe control platform

Widely used in control systems for gas turbine, steam turbine, hydropower equipment

Support automatic control of equipment in large-scale process industries

Suitable for process control fields such as metal smelting in the petrochemical industry of power plants

Product imag
